THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF
BUD INDUSTRIES INC. ANY REPRODUCTION IN PART OR WHOLE WITHOUT
THE WRITTEN PERMISSION OF BUD INDUSTRIES INC. IS PROHIBITED.
DWG. NO.
ISSUE
CN-5714
REVISIONS
F
F
MATERIAL - ALUMINUM ALLOY #ADC-12
FINISH - NATURAL (CONTACT BUD FACTORY FOR
ALTERNATE FINISHES)
E
GASKET - RATED IP65 NEOPRENE, SELF-ADHESIVE,
3mm THICK, COLOR BLACK
.160
90° CSK.
E
SCREWS - STAINLESS STEEL, M3.5 x 12mm LG.,
CSK. HEAD, SELF-THREADING
ALL HOLE DIAMETERS HAVE .005 TOLERANCE.
ALL OTHER DIMENSIONS HAVE .015 TOLERANCE.
ENCLOSURES ARE SHIPPED UNASSEMBLED WITH
ALL ITEMS SHOWN.
D
A
10.810
C
DETAIL D
SCALE 6 : 1
D
10.810
5.196
2.440
1.50° DRAFT REF.
OUTSIDE & INSIDE
10.394
5.197
.157
D
2.644
.095 TYP.
.059
C
.097 TYP.
C
B
B
.105 TYP.
6.606
6.890
6.456
.080 TYP.
6.890
.065
TYP.
.080
.240
TYP.
B
A
TAPPED M3.5 (6x)
SECTION A-A
C
SECTION C-C
2.505 INSIDE
CLEAR HT.
B
10.526
SECTION B-B
BODY
COVER
PARTS LIST
AS NOTED
A
+/-.005 BETWEEN HOLE CENTERS
+/-.015 FROM SHEARED EDGE
+/-.032 FROM A BENT SURFACE
+/-.062 BETWEEN ASSEMBLED
SURFACES
UNLESS OTHERWISE SPECIFIED
MATERIAL
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
APPROVALS DATE
DRAWN
DAB
3-31-06
CHECKED
BUD INDUSTRIES INC.
DIE CAST ALUMINUM
ENCLOSURE
A
AS NOTED
CN-5714
C
QTY.
USED ON
FINISH
DO NOT SCALE DRAWING
APPROVED
SIZE DWG. NO.
SCALE CAD FILE:
SHEET
REV.
1 OF 1
